Description
- SOUND GENERATOR
- Piano Sound
- Piano Sound: SuperNATURAL Piano Modeling
- Max. Polyphony
- Piano: Limitless (solo playing using “Concert Piano, Ballad Piano, Mellow Piano, and Bright Piano” tones)
Other: 384 - Tones
- Piano: 15 tones
E.Piano: 16 tones
Strings: 11 tones
Organ: 15 tones
Pad: 15 tones
Other: 278 tones (including 8 drum sets, 1 SFX set) - KEYBOARD
- Keyboard
- PHA-50 Keyboard: Wood and Plastic Hybrid Structure, with Escapement and Ebony/Ivory Feel (88 keys)
- Touch Sensitivity
- Key Touch: 100 types, fixed touch
Hammer Response - Keyboard Modes
- Whole
Dual
Split (split point adjustable) - SPEAKER SYSTEM
- Speakers
- Speakers: 8 x 12 cm (3-3/16 x 4-3/4 inches) x 2 (with speaker box)
Dome Tweeters: 2.5 cm (1 inches) x 2 - HEADPHONES
- Headphones
- capable of Headphones 3D Ambience
- TUNING, VOICING
- Master Tuning
- 415.3–466.2 Hz (adjustable in increments of 0.1 Hz)
- Temperament
- 10 types (Equal, Just Major, Just Minor, Pythagorean, Kirnberger I, Kirnberger II, Kirnberger III, Meantone, Werckmeister, Arabic), selectable temperament key
- Effects
- Ambience
Equalizer (3-band digital equalizer)
Only for organ tones:
Rotary Speaker Effect
Only for E.Piano tones:
Modulation Speed - Piano Designer (Only for “Concert Piano, Ballad Piano, Mellow Piano, and Bright Piano” tones)
- Lid
Key Off Noise
Hammer Noise
Duplex Scale
Full Scale String Resonance
Damper Resonance
Key Off Resonance
Cabinet Resonance
Soundboard Type
Damper Noise
Single Note Tuning
Single Note Volume
Single Note Character - Rated Power Output
- 25 W x 2
5 W x 2 - Volume Level (SPL)
- 107 dB (This value was measured according to the method that is based on Roland’s technical standard.)
- BLUETOOTH
- Bluetooth
- Audio: Bluetooth Ver. 3.0 (Supports SCMS-T content protection)
MIDI, Turning music sheet: Bluetooth Ver. 4.0
*The Bluetooth feature may not be available, depending on the country where the product is purchased. - MIC
- Effects
- Compressor
Doubling
Echo - Controls
- Mic Gain knob
Mic Volume slider - DATA PLAYBACK
- Playable Software
- Standard MIDI Files (Format 0, 1)
Audio File (WAV, 44.1 kHz, 16-bit linear format, MP3, 44.1kHz, 64kbps–320kbps, require USB Flash Memory) - Internal Songs
- Total 10 songs
- RECORDER
- Recordable Software
- Standard MIDI Files (Format 0, Approx. 70,000 notes memory)
Audio File (WAV, 44.1 kHz, 16-bit linear format, require USB Flash Memory) - CONVENIENT FUNCTIONS
- Convenient Functions
- Metronome (adjustable Tempo/Beat/Down beat/Pattern/Volume/Tone)
Transpose (Keyboard/Song: in semitones)
Registration (30 registrations, capable of pedal shift)
Registration Set
Tone Demo
Auto Off - OTHER
- Display
- Graphic LCD 132 x 32 dots
- Controls
- Volume slider
Equalizer sliders (Low/Mid/High)
Part sliders (Lower/Upper)
Song Vol. slider
Speaker switch - Connectors
- DC In jack
Pedal (Damper/R, Sostenuto/C *1, Soft/L *1) jacks: TRS 1/4-inch phone type
Input jacks: Stereo miniature phone type
Output (L/Mono, R) jacks: 1/4-inch phone type
Mic Input jack: 1/4-inch phone type
MIDI (Out/In) connectors
USB Computer port: USB B type
USB Memory port: USB A type
Phones jack x 2: Stereo miniature phone type, Stereo 1/4-inch phone type
*1: Assignable - Power Supply
- AC adaptor
- Power Consumption
- 12 W
- Accessories
- Owner’s Manual
Leaflet “USING THE UNIT SAFELY”
AC adaptor
Power cord
Music rest
Damper pedal (DP-10; capable of continuous detection) - Option (sold separately)
- Dedicated stand: KSC-90
Dedicated pedal board: KPD-90
Keyboard stand: KS-G8B, KS-18Z, KS-12
Pedal unit: RPU-3
Damper pedal: DP series
Pedal switch: DP-2 (*2)
Expression pedal: EV-5
USB Flash Memory*2 Cannot use for Damper/R. - SIZE (DETACHED MUSIC REST)
- Width
- 1,340 mm
52-13/16 inches - Depth
- 390 mm
15-3/8 inches - Height
- 136 mm
5-3/8 inches - SIZE (FP-90 WITH KSC-90 AND MUSIC REST)
- Width
- 1,340 mm
52-13/16 inches - Depth
- 418 mm
16-1/2 inches - Height
- 932 mm
36-3/4 inches - WEIGHT (FP-90 WITH MUSIC REST)
- Weight
- 23.6 kg
52 lbs. 1 oz. - WEIGHT (FP-90 WITH KSC-90, KPD-90, AND MUSIC REST)
- Weight
- 37.8 kg
83 lbs. 6 oz.
- The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Roland is under license.
